Description

Port of registry : Jazan. Flag : Saudi Arabia Classification society : Lloyd’s Register of Shipping. Year built : 2017. Material : Aluminium both hull and superstructure. Fuel oil: 8.00 m3 can be increased to 13 m3. Top Speed: 25 knots. Eco Speed: 19 knots. 30 passengers inside and up to 30 persons outside seated. Range: 700 Nautical miles.
Date Launched: 2017 Length: 19.70m (64ft 7.6in) Beam: 8.2m (26ft 10.8in) Draft: 4.5m (14ft 9.1in) Note: Engine : 2x MTU, type 8V2000 M72 Location: Saudi Arabia

Specifications

Accommodation

30 passengers inside and up to 30 persons outside seated

Construction

Material: Aluminium both hull and superstructure
Length overall: 19.70m
Max breadth: 8.2m
Free deck area: 50 sqm
Depth moulded: 4.5m
22,5 kW / 28,1 kVA, 3 phase,
230 V / 400V, 50 Hz
Summer Loaded Draft: 1.70 m
GRT: 39t
NRT: 42t

Fuel oil: 8.00 m3 can be increased to 13 m3
Fresh water: 1.14 m3
Wastewater: 1.20 m3
Dirty oil: 1.20 m3
Dead weight: 16t (incl. fuel, persons, cargo etc.)

Free Deck Space: 50m2
Max Deck Load: 1.5 ton/m2
Fore Ward Deck Area: 10ft container
Aft Deck Area: 10ft container

Navigation Equipment

Gyro compass, Magnetic Echo sounder, VHF, Radar, GPS, Navtex, AIS, Electronic chart

Engine(s)

Propulsion : two fixed pitch propellers
Main Engines : 2x MTU, type 8V2000 M72
Output : 1930 hp total at 2250 rpm
Gearboxes : 2x Reintjes ZWVS 440/1 (two speed)
Generators : 2x Caterpillar, type C2.2T
Output : 22,5 kW / 28,1 kVA, 3 phase, 230 V / 400V, 50 Hz

DECK MACHINERY
Deck Equipment : Rubber “D” fender heavy duty bow fender container lashing points
Knuckle Boom Crane : Heila 5-2S, about 750 kg at 6.90m
Jacobs Ladder : Starboard side


Top Speed: 25knots
Eco Speed: 19knots
Range: 700 Nautical miles

Certification

Type of ship: Damen Fast Crew Supplier 2008
Port of registry: Jazan
Flag: Saudi Arabia
Classification society: Lloyd’s Register of Shipping
Year built: 2017

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
